Fonctions G pour contours de tournage
Contour de tournage
Contour de tournage
Définition de la pièce brute
Eléments de forme du contour de tournage
G20-Géo
Mandrin cylindre/tube
G22-Géo
Gorge (standard)
G21-Géo
Pièce moulée
G23-Géo
Gorge/tournage franc
Eléments de base du contour de tournage
G24-Géo
Filetage avec dégagement
G0-Géo
Point de départ du contour
G25-Géo
Contour de dégagement
G1-Géo
Droite
G34-Géo
Filetage (standard)
G2-Géo
Arc sens horaire, cotation du centre
en incrémental
G37-Géo
Filetage (général)
G3-Géo
Arc sens anti-horaire, cotation du
centre en incrémental
G49-Géo
Perçage au centre de rotation
G12-Géo
Arc sens horaire, cotation du centre
en absolu
Commandes auxiliaires pour définition contour
G13-Géo
Arc sens anti-horaire, cotation du
centre en absolu
Sommaire: Attributs pour la définition du
contour
G38-Géo
Réduction de l'avance
G44
Point de séparation
G52-Géo
Surépaisseur
G95-Géo
Avance par tour
G149-Géo Correction additionnelle
