HEIDENHAIN MANUALplus 620, CNC PILOT 640
563
7.
2 Création A
u
to
matique du Plan de tr
a
v
ail (CAP)
Suite chronologique d'usinage "Dégagement"
Tous
–
Tous les types de gorge ; usinage radial/axial ; extérieur et
intérieur
Forme S, D, A, FK
–
Usinage radial/axial - extérieur et intérieur
Forme S, D, A, FK
extérieur
Usinage radial – extérieur
Forme S, D, A, FK
intérieur
Usinage radial – intérieur
Forme S, D, A, FK
Ext./front.
Usinage axial – extérieur
Forme S, D, A, FK
Int./front.
Usinage axial – intérieur
Usinage principal
Usinage auxiliaire
Lieu
Exécution
Usinage principal
Usinage auxiliaire
Lieu
Exécution
Dégagement
Analyse de contour/usinage : calculer les éléments de forme
"Dégagements" :
Forme H – usinage avec trajectoires isolées, outil à reproduire
(type 22x)
Forme K – usinage avec trajectoires isolées, outil à reproduire
(type 22x)
Forme U – usinage avec trajectoires isolées, outil d'usinage de
gorge (type 15x)
Chronologie : usinage extérieur avant l'usinage intérieur ;
usinage radial avant l'usinage axial
Tous
–
Tous types de gorge - usinage extérieur et intérieur
Tous
extérieur
Tous types de gorge - usinage extérieur
Tous
intérieur
Tous types de gorge - usinage intérieur
Forme H, K, U
–
Usinage radial/axial - extérieur et intérieur
Forme H, K, U
extérieur
Usinage – extérieur
Forme H, K, U
intérieur
Usinage – intérieur
