UNITs : Sommaire
9.2 UNITS – Gr
oupe P
e
rçag
e
9.2
UNITS – Groupe Perçage
Groupe Perçage au centre
Groupe Perçage ICP axe C
Groupe Perçage axe C face frontale
UNIT
Description
Page
G74_Centr
G74 Perçage au centre
Perçage et perçage profond avec X=0
G73_Centr
G73 Taraudage au centre
Taraudage à X=0
UNIT
Description
Page
G74_ICP_C
G74 Perçage ICP axe C
Perçage et perçage profond avec motif ICP
G73_ICP_C
G73 Taraudage ICP axe C
Taraudage avec motif ICP
G72_ICP_C
G72 Alésage, lamage ICP axe C
Taraudage avec motif ICP
UNIT
Description
Page
G74_Perç_Front_C
G74 Trou unique
Perçage et perçage profond d'un seul trou
G74_Lin_Front_C
G74 Perçage motif linéaire
Perçage et perçage profond motif linéaire de trous
G74_Cir_Front_C
G74 Perçage motif circul.
Perçage et perçage profond d'un cercle de trous
G73_Tar_Front_C
G73 Taraudage
Taraudage trou unique
G73_Lin_Front_C
G73 Taraudage motif linéaire
Taraudage d'un motif linéaire de trous
G73_Cir_Front_C
G73 Taraudage Motif circulaire
Taraudage d'un cercle de trous
