Cycles palpeurs dans le mode automatique – HEIDENHAIN SW 54843x-03 DIN Programming Manuel d'utilisation
Page 457
![background image](/files/815784/content/doc457.png)
HEIDENHAIN MANUALplus 620, CNC PILOT 640
457
5.1 Génér
a
lités sur les cy
cles palpeurs (option de logiciel)
Cycles palpeurs dans le mode automatique
La commande propose de nombreux cycles de palpage pour
différentes utilisations.
Etalonnage du palpeur à commutation
Mesurer le cercle, le cercle gradué, l'angle et la position de l'axe C
Compensation d'alignement
Mesure un point, mesure deux points
Chercher un trou ou un tenon
Initialiser le point zéro dans l'axe Z ou l'axe C
Etalonnage automatique d'outils
Les cycles palpeurs sont programmés en DIN PLUS par le biais des
fonctions G. Tout comme les cycles d’usinage, les cycles palpeurs
utilisent des paramètres de transfert.
Pour simplifier la programmation, la TNC affiche un écran d'aide
pendant la définition du cycle. L'écran d'aide affiche les paramètres de
programmation (voir figure de droite).
Les cycles palpeurs enregistrent les informations d'état et le résultat
des mesures dans la variable #i99. En fonction des paramètres de
programmation dans le cycle palpeur, vous pouvez consulter les
valeurs suivantes.
Résultat #i99
Signification
< 999997
Résultat de la mesure
999999
Palpeur non dévié
-999999
Programmation d'un axe de mesure non valide
999998
Dépassement de l'écart maximal WE
999997
Dépassement de la valeur de correction maximale E
