4 programmation din – HEIDENHAIN SW 54843x-03 DIN Programming Manuel d'utilisation
Page 18
![background image](/files/815784/content/doc018.png)
18
4.1 Programmation en mode DIN/ISO ..... 190
Commandes de géométrie et d'usinage ..... 190
Programmation du contour ..... 191
Séquences CN de programmes DIN ..... 193
Créer, modifier ou effacer des séquences CN ..... 194
Paramètres d'adresse ..... 195
Sous-programmes, programmes experts ..... 197
Conversion des programmes CN ..... 197
Programmes DIN issus d'une commande antérieure ..... 198
Groupe de menu "Géométrie" ..... 200
Groupe de menu "Usinage" ..... 200
4.2 Définition de la pièce brute ..... 201
Mandrin cylindre/tube G20-Géo ..... 201
Pièce moulée G21-Géo ..... 201
4.3 Eléments de base du contour de tournage ..... 202
Point initial contour de tournage G0–Géo ..... 202
Attributs d'usinage pour les éléments de forme ..... 203
Droite sur contour G1–Géo ..... 204
Arc de cercle de contour G2/G3 Géo ..... 206
Arc de cercle de contour G12/G13 Géo ..... 207
4.4 Eléments de forme d'un contour de tournage ..... 209
Gorge (standard) G22–Géo ..... 209
Gorge (générale) G23–Géo ..... 211
Filet avec dégagement de filetage G24–Géo ..... 213
Contour du dégagement G25-Géo ..... 214
Filet (standard) G34-Géo ..... 218
Filetage (général) G37–Géo ..... 219
Perçage (au centre) G49–Géo ..... 221
4.5 Attributs pour la définition du contour ..... 222
Réduction d'avance G38-Géo ..... 222
Attributs pour éléments de superposition G39-Géo ..... 223
Point de séparation G44 ..... 224
Surépaisseur G52-Géo ..... 224
Avance par tour G95-Géo ..... 225
Correction additionnelle G149-Géo ..... 225
4.6 Contours axe C – Principes de base ..... 226
Contours de fraisage, position ..... 226
