HEIDENHAIN MANUALplus 620, CNC PILOT 640
447
4.37 Relation entr
e les commandes de géométr
ie et d'usinag
e
4.37 Relation entre les commandes
de géométrie et d'usinage
tournage
Fonction
Géométrie.
Usinage
Eléments uniques
G0..G3
G12/G13
G810 Ebauche longitudinale
G820 Ebauche transversale
G830 Ebauche parallèle au contour
G835 Parallèle au contour avec outil neutre
G860 Cycle universel d'usinage de gorges
G869 Tournage de gorge
G890 Cycle de finition de contour
Gorge
G22 (standard)
G860 Cycle universel d'usinage de gorges
G870 Cycle simple de gorges
G869 Tournage de gorge
Gorge
G23
G860 Cycle universel d'usinage de gorges
G869 Tournage de gorge
Filetage avec
dégagement
G24
G810 Ebauche longitudinale
G820 Ebauche transversale
G830 Ebauche parallèle au contour
G890 Cycle de finition de contour
G31 Cycle de filetage
Dégagement
G25
G810 Ebauche longitudinale
G890 Cycle de finition de contour
Filet
G34 (standard)
G37 (général)
G31Cycle de filetage
Perçage
G49 (centre de rotation)
G71 Perçage simple
G72 Alésage, lamage, etc.
G73 Taraudage
G74 Perçage profond
