Groupe gorges, Groupe filetage, 1 units – gr oupe t our nag e – HEIDENHAIN SW 54843x-03 DIN Programming Manuel d'utilisation
Page 595: Groupe gorges groupe filetage
![background image](/files/815784/content/doc595.png)
HEIDENHAIN MANUALplus 620, CNC PILOT 640
595
9.1 UNITS – Gr
oupe T
our
nag
e
Groupe Gorges
Groupe filetage
UNIT
Description
Page
G860_ICP
G860 Gorge de contour ICP
Gorges de contour ICP
G869_ICP
G869 Gorge ICP
Gorge contour ICP
G860_G80
G860 Gorge contour directe
Gorge avec intro. directe du contour
G869_G80
G869 Gorge direct
Gorge avec intro. directe du contour
G859_Cut_off
G859 Tronçonnage
Tronçonnage d'une barre, intro.directe de la position
G85x_Cut_H_K_U
G85X Dégagement (H, K, U)
Création de dégagement forme H, K et U
UNIT
Description
Page
G32_MAN
G32 Filetage simple
Filetage avec description directe du contour
G31_ICP
G31 Filetage ICP
Filetage sur n'importe quel contour ICP
G352_API
G352 Filetage API
Filetage API avec description directe du contour
G32_KEG
G32 Filetage conique
Filetage conique avec description directe du contour
