256
Programmation DIN
4.1
1
A
v
ance, vit
e
sse de r
o
tation
Interruption d'avance G64
La fonction G64 interrompt brièvement l'avance programmée. G64 est
une fonction modale.
Activation : Programmer G64 avec "E et F"
Désactivation: Programmer G64 sans paramètre
Avance par dent Gx93
Gx93 (x: broche 1...3) définit l'avance dépendant de la motorisation
en rapport avec le nombre de dents de la fraise.
Beispiel: G64
. . .
N1 T3 G95 F0.25 G96 S200 M3
N2 G64 E0.1 F1 [interruption de l'avance
activée]
N3 G0 X0 Z2
N4 G42
N5 G1 Z0
N6 G1 X20 B-0.5
N7 G1 Z-12
N8 G1 Z-24 A20
N9 G1 X48 B6
N10 G1 Z-52 B8
N11 G1 X80 B4 E0.08
N12 G1 Z-60
N13 G1 X82 G40
N14 G64 [interruption de l'avance désactivée]
. . .
Paramètres
E
Durée de pause (0,01s < E < 99,99s)
F
Durée de pause (0,01s < E < 99,99s)
Beispiel: G193
. . .
N1 M5
N2 T1 G197 S1010 G193 F0.08 M104
N3 M14
N4 G152 C30
N5 G110 C0
N6 G0 X122 Z-50
N7 G...
N8 G...
N9 M15
. . .
Paramètres
F
Avance par dent en mm/dent ou en inch/dent
L'affichage de la valeur effective indique l'avance en mm/
tour.
