342
Programmation DIN
4.23 Instr
u
ctions ax
e C
4.23 Instructions axe C
Diamètre de référence G120
La fonction G120 définit le diamètre de référence du "développé de
l'enveloppe". Programmez la fonction G120 si vous utilisez "CY" pour
G110...G113. G120 est une fonction modale.
Décalage du point zéro de l'axe C G152
La fonction G152 définit le point zéro de l'axe C en coordonnées
absolues (référence : point de référence de l'axe C). Le point zéro est
actif jusqu'à la fin du programme.
Beispiel: G120
. . .
N1 T7 G197 S1200 G195 F0.2 M104
N2 M14
N3 G120 X100 [diamètre de référence]
N4 G110 C0
N5 G0 X110 Z5
N6 G41 Q2 H0
N7 G110 Z-20 CY0
N8 G111 Z-40
N9 G113 CY39.2699 K-40 J19.635
N10 G111 Z-20
N11 G113 CY0 K-20 J19.635
N12 G40
N13 G110 X105
N14 M15
. . .
Paramètres
X
Diamètre
Beispiel: G152
. . .
N1 M5
N2 T7 G197 S1010 G193 F0.08 M104
N3 M14
N4 G152 C30 [Décalage du point zéro de l'axe
C]
N5 G110 C0
N6 G0 X122 Z-50
N7 G71 X100
N8 M15
. . .
Paramètres
C
Angle : Position de la broche du "nouveau" point zéro de l'axe C
