436
Programmation DIN
4.35 F
onctions G des commandes antér
ieur
e
s
Beispiel: G25
%25.nc
[G25]
N1 T1 G95 F0.4 G96 S150 M3
N2 G0 X62 Z2
N3 G819 P4 H0 I0.3 K0.1
N4 G0 X13 Z0
N5 G1 X16 Z-1.5
N6 G1 Z-30
N7 G25 H7 I1.15 K5.2 R0.8 W30 FP1.5
N8 G1 X20
N9 G1 X40 Z-35
N10 G1 Z-55 B4
N11 G1 X55 B-2
N12 G1 Z-70
N13 G1 X60
N14 G80
FIN
Les paramètres que vous programmez sont prioritaires
– même si le tableau standard prévoit d'autres valeurs.
Dans les filetages intérieurs, indiquez le pas du filet
FP
car le diamètre de l'élément longitudinal ne
correspond pas au diamètre du filet. Si c'est la
Commande numérique qui se charge de déterminer le
pas de filet, de légers écarts sont à prévoir.
