HEIDENHAIN iTNC 530
9
T
y
pe de TNC, logiciel et f
onctions
Niveau de développement (fonctions Upgrade)
Parallèlement aux options de logiciel, d'importants nouveaux
développements du logiciel TNC sont gérés par ce qu'on appelle les
Feature Content Level (expression anglaise exprimant les niveaux de
développement). Vous ne disposez pas des fonctions FCL lorsque
votre TNC reçoit une mise à jour de logiciel.
Dans ce Manuel, ces fonctions sont signalées par l'expression FCL n;
n
précisant le numéro d'indice du niveau de développement.
L'acquisition payante des codes correspondants vous permet
d'activer les fonctions FCL. Pour cela, prenez contact avec le
constructeur de votre machine ou avec HEIDENHAIN.
Lorsque vous réceptionnez une nouvelle machine, toutes
les fonctions de mise à jour sont disponibles sans surcoût.
Fonctions FCL 4
Description
Représentation graphique de la zone
protégée avec contrôle anti-collision
DCM actif
Manuel d'utilisation
Superposition de la manivelle, axes à
l'arrêt, avec contrôle anti-collision DCM
actif
Manuel d'utilisation
Rotation de base 3D (compensation de
montage)
Manuel d'utilisation de
la machine
Fonctions FCL 3
Description
Cycle palpeur pour palpage 3D
Page 467
Cycles palpeurs pour l’initialisation
automatique de l'origine au centre
d'une rainure/d'un oblong
Réduction d'avance lors de l'usinage en
pleine matière d'une poche de contour
Manuel d'utilisation
Fonction PLANE : introduction d'un
angle d'axe
Manuel d'utilisation
Documentation utilisateur sous forme
de système d'aide contextuelle
Manuel d'utilisation
smarT.NC : programmer smarT.NC en
parallèle avec l'usinage
Manuel d'utilisation
smarT.NC : poche de contour sur motifs
de points
Pilote smarT.NC
