Cycles palpeurs : contrôle automatique des pièces
16.1 Pr
incipes de base
Exemple : fichier procès-verbal pour cycle palpeur 421 :
Procès-verbal mesure cycle 421 Mesure trou
Date: 30-06-2005
Heure: 6:55:04
Programme de mesure: TNC:\GEH35712\CHECK1.H
Valeurs nominales :
Centre axe principal : 50.0000
Centre axe secondaire: 65.0000
Diamètre: 12.0000
Valeurs limites prédéfinies :
Cote max. centre axe principal : 50.1000
Cote min. centre axe principal : 49.9000
Cote max. centre axe secondaire : 65.1000
Cote min. centre axe secondaire : 64.9000
Cote max. trou: 12.0450
Cote min. trou: 12.0000
Valeur effective : centre
Axe principal : 50.0810
Centre axe secondaire : 64.9530
Diamètre: 12.0259
Ecarts :
Centre axe principal : 0.0810
Centre axe secondaire : -0.0470
Diamètre: 0.0259
Autres résultats de mesure : hauteur de mesure : -5.0000
Fin procès-verbal de mesure
