Paramètres du cycle – HEIDENHAIN iTNC 530 (60642x-04) Cycle programming Manuel d'utilisation
Page 203
![background image](/files/816537/content/doc203.png)
HEIDENHAIN iTNC 530
203
7.
9 DONNEES TRA
C
E CONT
OUR (cy
c
le 270, DIN/ISO:
G270)
Paramètres du cycle
Mode d'approche/de sortie
Q390 : définition du
mode d'approche/de sortie :
Q390 = 1 :
Accostage tangentiel sur un arc de cercle
Q390 = 2 :
Accostage tangentiel sur une droite
Q390 = 3 :
Accostage sur une droite perpendiculaire
Correct. rayon (0=R0/1=RL/2=RR)
Q391: définition
de la correction de rayon:
Q391 = 0 :
Usiner le contour défini sans correction de rayon
Q391 = 1 :
Usiner le contour défini avec correction de rayon à
gauche
Q391 = 2 :
Usiner le contour défini avec correction de rayon à
droite
Rayon d'appr./Rayon de sortie
Q392 : n'est acif que
si vous avez sélectionné l'approche tangentielle sur
un arc de cercle. Rayon du cercle d'entrée/de sortie.
Plage d'introduction 0 à 99999,9999
Angle au centre
Q393 : n'est actif que si vous avez
sélectionné l'approche tangentielle sur un arc de
cercle. Angle d'ouverture du cercle d'entrée. Plage
d'introduction 0 à 99999,9999
Dist. pt auxiliaire
Q394 : n'est actif que si vous
avez sélectionné l'approche tangentielle sur une
droite ou perpendiculaire. Distance du point auxiliaire
à partir duquel la TNC doit aborder le contour. Plage
d'introduction 0 à 99999,9999
Exemple : Séquences CN
62 CYCL DEF 270 DONNÉES TRAC. CONTOUR
Q390=1
;MODE D'APPROCHE
Q391=1
;CORRECTION DE RAYON
Q392=3
;RAYON
Q393=+45
;ANGLE AU CENTRE
Q394=+2
;DISTANCE
