Cycles palpeurs : déterminer automatiquement l'erreur d'alignement de la pièce
14.1 Pr
incipes de base
14.1 Principes de base
Résumé
La TNC dispose de cinq cycles avec lesquels vous pouvez déterminer
et compenser l'erreur d'alignement de la pièce. Vous pouvez
également annuler une rotation de base avec le cycle 404 :
Cycle
Softkey
Page
400 ROTATION DE BASE
Détermination automatique à partir de
2 points, compensation par la fonction
Rotation de base
401 ROT 2 TROUS Détermination
automatique à partir de 2 trous,
compensation avec la fonction Rotation
de base
402 ROT AVEC 2 TENONS
Détermination automatique à partir de
2 tenons, compensation avec la
fonction Rotation de base
403 ROT AVEC AXE ROTATIF
Détermination automatique à partir de
deux points, compensation par rotation
du plateau circulaire
405 ROT AVEC AXE C Compensation
automatique d'un décalage angulaire
entre le centre d'un trou et l'axe Y
positif, compensation par rotation du
plateau circulaire
404 INIT. ROTAT. DE BASE
Initialisation d'une rotation de base au
choix
