Type de tnc, logiciel et fonctions – HEIDENHAIN iTNC 530 (60642x-04) Cycle programming Manuel d'utilisation
Page 4
![background image](/files/816537/content/doc004.png)
4
T
y
pe de TNC, logiciel et f
onctions
Type de TNC, logiciel et fonctions
Ce manuel décrit les fonctions dont disposent les TNCs à partir des
numéros de logiciel CN suivants :
La lettre E désigne la version Export de la TNC. Les versions Export de
la TNC sont soumises à la restriction suivante :
Interpolation linéaire sur 4 axes maximum
HSCI (HEIDENHAIN Serial Controller Interface) désigne la nouvelle
plateforme Hardware des commandes TNC.
HEROS 5 désigne le nouveau système d'exploitation des commandes
TNC basées sur HSCI.
A l'aide des paramètres machine, le constructeur peut adapter à sa
machine l'ensemble des possibilités dont dispose la TNC. Dans ce
manuel figurent ainsi des fonctions qui n'existent pas dans toutes les
TNC.
Exemple de fonctions TNC non disponibles sur toutes les machines :
Etalonnage d'outils à l'aide du TT
Nous vous conseillons de prendre contact avec le constructeur de
votre machine pour connaître les fonctions présentes sur votre
machine.
Type de TNC
Nr. de logiciel CN
iTNC 530, HSCI et HEROS 5
606420-04
iTNC 530 E, HSCI et HEROS 5
606421-04
Poste de programmation iTNC 530
HSCI
606424-04
