![background image](/files/816537/content/doc065.png)
HEIDENHAIN iTNC 530
65
2.4 T
a
bleaux de points
Ignorer certains points pour l'usinage
Dans la colonne FADE du tableau de points, vous pouvez marquer le
point défini sur une ligne sélectionnée de manière à ce qu'il ne soit pas
usiné.
Dans le tableau, sélectionner le point qui doit être
masqué
Sélectionner la colonne FADE
Activer le masquage ou
Désactiver le masquage
Définir la hauteur de sécurité
Dans la colonne HAUTEUR DE SECURITE, vous pouvez définir une
hauteur de sécurité séparée pour chaque point. La TNC positionne
l'outil à cette valeur dans l'axe d'outil avant d'approcher la position
dans le plan d'usinage (voir également „Appeler le cycle en liaison
avec les tableaux de points” à la page 67).
Pour ignorer l'usinage du point correspondant marqué en
mode Exécution de programme, vous devez également
initialiser la softkey Occulter séquences à ON.
