HEIDENHAIN iTNC 530
407
15.13 PT DE REF SUR UN AXE (cy
c
le
41
9, DIN/ISO:
G41
9
)
2 TCH PROBE 413 PT REF EXT. CERCLE
Q321=+25
;CENTRE 1ER AXE
Centre du cercle : coordonnée X
Q322=+25
;CENTRE 2ÈME AXE
Centre du cercle : coordonnée Y
Q262=30
;DIAMÈTRE NOMINAL
Diamètre du cercle
Q325=+90
;ANGLE INITIAL
Angle en coordonnées polaires pour 1er point de palpage
Q247=+45
;INCRÉMENT ANGULAIRE
Incrément angulaire pour calculer les points de palpage 2 à 4
Q261=-5
;HAUTEUR DE MESURE
Coordonnée dans l'axe du palpeur où s'effectue la mesure
Q320=2
;DISTANCE D'APPROCHE
Distance d'approche en sus de PM6140
Q260=+10
;HAUTEUR DE SÉCURITÉ
Hauteur à laquelle l'axe du palpeur peut se déplacer sans risque de
collision
Q301=0
;DÉPLAC. HAUT. SÉCU.
Entre les points de mesure, ne pas aller à hauteur de sécurité
Q305=0
;NR. DANS TABLEAU
Initialiser l'affichage
Q331=+0
;POINT DE RÉFÉRENCE
Initialiser l'affichage X à 0
Q332=+10
;POINT DE RÉFÉRENCE
Initialiser l'affichage Y à 10
Q303=+0
;TRANS. VAL. MESURE
Sans fonction car l'affichage doit être initialisé
Q381=1
;PALP. DS AXE PALPEUR
Initialiser également le point d'origine dans l'axe du palpeur
Q382=+25
;1ÈRE COO. DANS AXE PALP.
Point de palpage coordonnée X
Q383=+25
;2ÈME COO. DANS AXE PALP.
Point de palpage coordonnée Y
Q384=+25
;3ÈME COO. DANS AXE PALP.
Point de palpage coordonnée Z
Q333=+0
;POINT DE RÉFÉRENCE
Initialiser l'affichage Z à 0
Q423=4
;NB POINTS DE MESURE
Nombre de points de mesure
Q365=1
;TYPE DÉPLACEMENT
Positionner au point de palpage suivant sur un arc de cercle ou une
droite
3 CALL PGM 35K47
Appeler le programme d'usinage
4 END PGM CYC413 MM
