HEIDENHAIN iTNC 530
299
1
1
.9 PLAN D'USINA
GE (cy
c
le 1
9
, DIN/ISO:
G80, option logicielle
1)
Positionner les axes rotatifs automatiquement
Si le cycle 19 positionne automatiquement les axes rotatifs :
La TNC ne positionne automatiquement que les axes asservis.
Dans la définition du cycle, en plus des angles d'inclinaison, vous
devez introduire une distance d'approche et une avance pour le
positionnement des axes inclinés.
N'utiliser que des outils préréglés (la longueur d'outil totale doit être
définie).
Dans l'opération d'inclinaison, la position de la pointe de l'outil reste
pratiquement inchangée par rapport à la pièce.
La TNC exécute l'inclinaison avec la dernière avance programmée.
L'avance max. pouvant être atteinte dépend de la complexité de la
tête pivotante (table inclinée).
Exemples de séquences CN :
10 L Z+100 R0 FMAX
11 L X+25 Y+10 R0 FMAX
12 CYCL DEF 19.0 PLAN D'USINAGE
Définir l’angle pour le calcul de la correction
13 CYCL DEF 19.1 A+0 B+45 C+0 F5000 DIST50
Définir aussi l'avance et la distance
14 L Z+80 R0 FMAX
Activer la correction dans l’axe de broche
15 L X-8.5 Y-10 R0 FMAX
Activer la correction dans le plan d’usinage
