HEIDENHAIN iTNC 530
489
1
8
.4 MESURE CINEMA
TIQUE (cy
c
le 451, DIN/ISO:
G451, option)
Jeu
Le jeu à l'inversion est un jeu très faible entre le capteur rotatif
(système de mesure angulaire) et la table, généré lors d'un
changement de direction, Si les axes rotatifs ont du jeu en dehors de
la chaîne d'asservissement, ils peuvent générer d'importantes erreurs
lors de l'inclinaison.
Le paramètre à introduire Q432 permet d'activer la mesure du jeu à
l'inversion. Pour cela, introduisez un angle que la TNC utilise comme
angle de dépassement. Le cycle exécute deux mesures par axe
rotatif. Si vous introduisez la valeur angulaire 0, la TNC ne détermine
pas de jeu à l'inversion.
La TNC n'applique aucune compensation automatique de
jeu à l'inversion.
Si le rayon du cercle de mesure est < 1 mm, la TNC ne
détermine pas le jeu à l'inversion. Plus le rayon du cercle
de mesure est grand, plus le jeu à l'inversion déterminé
par la TNC est précis (voir également „Fonction journal” à
la page 495).
Aucune détermination du jeu à l'inversion n'est possible
lorsque le paramètre machine MP6602 est initialisé, ou
avec un axe Hirth.
