Cycles d'usinage : usinage ligne à ligne
1
0
.1 Pr
incipes de base
10.1 Principes de base
Tableaux récapitulatifs
La TNC dispose de quatre cycles destinés à l’usinage de surfaces aux
caractéristiques suivantes :
générées par un système de CFAO
planes et rectangulaires
planes et pentues
inclinées quelconques
gauches
Cycle
Softkey
Page
30 EXECUTION DE DONNEES 3D
pour usinage ligne à ligne de données
3D en plusieurs passes
230 LIGNE A LIGNE
pour surfaces planes et rectangulaires
231 SURFACE REGLEE
pour surfaces pentues, inclinées ou
gauches
232 SURFACAGE
pour surfaces planes rectangulaires,
avec indication de surépaisseur et
plusieurs passes
