HEIDENHAIN iTNC 530
43
1
.2 Gr
oupes de cy
cles disponibles
1.2 Groupes de cycles disponibles
Résumé des cycles d'usinage
La barre de softkeys affiche les différents groupes de
cycles
Si nécessaire, commuter vers les cycles d'usinage
personnalisés du constructeur. De tels cycles
d'usinage peuvent être intégrés par le constructeur
de votre machine
Groupe de cycles
Softkey
Page
Cycles pour perçage profond, alésage à l'alésoir/à l'outil et lamage
Cycles de taraudage, filetage et fraisage de filets
Cycles de fraisage de poches, tenons, rainures
Cycles de création de motifs de points, p. ex. cercle de trous ou grille de trous
Cycles SL (Subcontur-List) pour l'usinage parallèle à un contour complexe, constitué de plusieurs
contours partiels superposés, interpolation sur corps d'un cylindre
Cycles d’usinage ligne à ligne de surfaces planes ou gauches
Cycles de conversion de coordonnées, avec lesquels les contours peuvent être décalés,
orientés, inversés, agrandis ou réduits
Cycles spéciaux : temporisation, appel de programme, orientation broche, tolérance, gravage,
tournage interpolé (option)
