198
Cycles d'usinage : poche de contour, tracé de contour
7.
7 FINITION EN PR
OFONDEUR (cy
c
le 23, DIN/ISO:
G123)
7.7 FINITION EN PROFONDEUR
(cycle 23, DIN/ISO: G123)
Mode opératoire du cycle
Approche douce de l'outil (cercle tangentiel vertical) vers la face à
usiner, à condition qu'il y ait suffisamment de place pour cette
opération. Si il n'y a pas suffisamment de place, la TNC déplace l'outil
verticalement à la profondeur. L'outil fraise ensuite ce qui reste après
l'évidement, soit la valeur de la surépaisseur de finition.
Attention lors de la programmation !
La TNC détermine automatiquement le point initial pour la
finition. Le point de départ dépend de la répartition des
contours dans la poche.
Le rayon d'approche pour le prépositionnement à la
profondeur finale est fixe et il est indépendant de l'angle
de plongée de l'outil.
Attention, risque de collision !
Avec le paramètre machine 7441 - bit 0, vous définissez si
la TNC doit délivrer un message d'erreur (bit 0=0), ou non
(bit 0=1), si la broche ne fonctionne pas lors de l'appel d'un
cycle. Cette fonction doit également être adaptée par le
constructeur de votre machine.
