472
Cycles palpeurs : fonctions spéciales
1
7.7 P
A
LP
A
G
E RAPIDE (cy
c
le 441, DIN/ISO:
G441, f
onction FCL 2)
17.7 PALPAGE RAPIDE (cycle 441,
DIN/ISO: G441, fonction FCL 2)
Mode opératoire du cycle
Le cycle palpeur 441 permet de configurer divers paramètres du
palpeur (p. ex.l'avance de positionnement) et ce, de manière globale
pour tous les cycles palpeurs utilisés par la suite. Ceci facilite
l'optimisation du programme et raccourcit du même coup le temps
d'usinage totale.
Attention lors de la programmation!
Remarques avant de programmer
Il n'y a aucun mouvement de machine avec le cycle 441
qui ne sert qu'à configurer divers paramètres de palpage.
END PGM
, M02, M30 annulent les configurations globales du
cycle 441.
Vous ne pouvez activer le repositionnement angulaire
(paramètre de cycle Q399) que si le paramètre-machine
6165=1. La modification du paramètre-machine 6165 ne
nécessite aucun réétalonnage du palpeur.
