27
TNC 410, TNC 426, TNC 430 HEIDENHAIN
Exemple 1
Une seule pièce doit comporter un trou profond de 20 mm. Après
avoir bridé et dégauchi la pièce, puis initialisé le point de référence,
le trou peut être programmé en quelques lignes, puis usiné.
L‘outil est pré-positionné tout d‘abord au dessus de la pièce à l‘aide
de séquences G00 et G01 (droites), puis positionné à une distance
d‘approche de 5 mm au-dessus du trou. Celui-ci est ensuite usiné à
l‘aide du cycle G83 PERCAGE PROFOND.
%$MDI G71 *
N10 G99 T1 L+0 R+5 *
N20 T1 G17 S2000 *
N30 G00 G40 G90 Z+200 *
N40 X+50 Y+50 M3 *
N50 G01 Z+2 F2000 *
N60 G83
P01 +2
P02 -20
P03 +10
P04 0,5
P05 250 *
N70 G79 *
N80 G00 G40 Z+200 M2 *
N99999 %$MDI G71 *
La fonction des droites est décrite au chapitre „6.4 Contournages –
Coordonnées cartésiennes“ et le cycle G83 PERCAGE PROFOND
sous „8.3 Cycles de perçage“.
définir out: outil zéro, rayon 5
appeler out: axe de broche Z,
vitesse de rotation broche 2000 t/min.
dégager out (avance rapide)
positionner out en avance rapide au-dessus du trou,
marche broche
positionner out à 5 mm au-dessus du trou
définir cycle G83 PERCAGE PROFOND:
distance d‘approche out au-dessus du trou
profondeur de trou (signe = sens de l‘usinage)
profondeur de la passe avant le retraît
temporisation au fond du trou, en secondes
avance de perçage
appeler le cycle G83 PERCAGE PROFOND
dégager out
fin du programme
3.1 Programmation et exécution d‘usinages simples
Out = outil
Dkap2-3.pm6
28.06.2006, 14:54
