3etalonner des pièces avec palpeurs 3d, 3 etalonner des pièces avec palpeurs 3d – HEIDENHAIN TNC 426B (280 472) ISO programming Manuel d'utilisation
Page 322
TNC 410, TNC 426, TNC 430 HEIDENHAIN
307
12.3Etalonner des pièces
avec palpeurs 3D
Les TNC 426, TNC 430 dispose d'un grand nombre de
cycles de mesure avec lesquels vous pouvez aisément
étalonner les pièces. Ces cycles sont décrits dans un
Manuel d'utilisation séparé. Si vous avez besoin de
ce Manuel Cycles palpeurs, prenez contact avec
HEIDENHAIN.
Le palpeur 3D vous permet de calculer:
■
les coordonnées d‘une position et, à partir de là,
■
les cotes et angles sur la pièce
Définir la coordonnée d‘une position sur la pièce
bridée
ú
Sélectionner la fonction de palpage: appuyer sur la
softkey PALPAGE POS
ú
Positionner le palpeur à proximité du point de palpage
ú
Sélectionner simultanément le sens du palpage et
l‘axe auquel doit se référer la coordonnée:
sélectionner la softkey correspondante
ú
Lancer la procédure de palpage: appuyer sur la touche
START externe
La TNC affiche comme point de référence la coordonnée du point
de palpage.
Définir les coordonnées d‘un coin dans le plan
d‘usinage
Calculer les coordonnées d‘un coin tel que décrit au paragraphe
„Coin pris comme point de référence“. La TNC affiche comme point
de référence les coordonnées du coin ayant fait l‘objet d‘une
opération de palpage.
12.3 Etalonner des pièces avec palpeurs 3D
Okap12.pm6
28.06.2006, 14:54
307
