6 exemples de programmation – HEIDENHAIN TNC 426B (280 472) ISO programming Manuel d'utilisation
Page 267
![background image](/files/816114/content/doc267.png)
251
TNC 410, TNC 426, TNC 430 HEIDENHAIN
N190 G98 L1 *
N200 G00 G40 G90 X+15 Y+10 M3 *
N210 L2,0 *
N220 X+45 Y+60 *
N230 L2,0 *
N240 X+75 Y+10 *
N250 L2,0 *
N260 G98 L0 *
N270 G98 L2 *
N280 Z+2 M99 *
N290 G91 X+20 M99 *
N300 Y+20 M99 *
N310 X-20 G90 M99 *
N320 G98 L0 *
N999999 %SP2 G71 *
Début sous-programme 1: schéma de trous complet
Aborder le point initial de la série de trous 1
Appeler sous-programme 2 pour la série de trous
Aborder le point initial de la série de trous 2
Appeler sous-programme 2 pour la série de trous
Aborder le point initial de la série de trous 3
Appeler sous-programme 2 pour la série de trous
Fin du sous-programme 1
Début sous-programme 2: série de trous
1er perçage avec cycle d‘usinage actif
Aborder le 2ème trou, appeler le cycle
Aborder le 3ème trou, appeler le cycle
Aborder le 4ème trou, appeler le cycle
Fin du sous-programme 2
9.6 Exemples de programmation
N190 G98 L1 *
N200 G00 G40 G90 X+15 Y+10 M3 *
N210 L2,0 *
N220 X+45 Y+60 *
N230 L2,0 *
N240 X+75 Y+10 *
N250 L2,0 *
N260 G98 L0 *
N270 G98 L2 *
N280 Z+2 M99 *
N290 G91 X+20 M99 *
N300 Y+20 M99 *
N310 X-20 G90 M99 *
N320 G98 L0 *
N999999 %SP2 G71 *
Début sous-programme 1: schéma de trous complet
Aborder le point initial de la série de trous 1
Appeler sous-programme 2 pour la série de trous
Aborder le point initial de la série de trous 2
Appeler sous-programme 2 pour la série de trous
Aborder le point initial de la série de trous 3
Appeler sous-programme 2 pour la série de trous
Fin du sous-programme 1
Début sous-programme 2: série de trous
1er perçage avec cycle d‘usinage actif
Aborder le 2ème trou, appeler le cycle
Aborder le 3ème trou, appeler le cycle
Aborder le 4ème trou, appeler le cycle
Fin du sous-programme 2
