14 Tableaux et sommaires
358
14.3 Inf
or
mations t
e
c
hniques
Conversions de coordonnées
■
Décalage du point zéro
■
Image miroir
■
Rotation
■
Facteur échelle
■
Inclinaison du plan d'usinage (sauf TNC 410)
Utilisation d‘un palpeur 3D
■
Fonctions de palpage pour l'initialisation du point de référence
et pour l'étalonnage automatique de la pièce
■
Digitalisation de formes 3D avec palpeur mesurant
(option, dialogue Texte clair seulement, sauf TNC 410)
■
Digitalisation de formes 3D avec palpeur à commutation
(option, dialogue Texte clair seulement)
■
Etalonnage automatique d'outils avec TT 120 (dialogue Texte clair
seulement)
Fonctions arithmétiques
■
Fonctions de calcul de base +, –, x et ¸
■
Fonctions trigonométriques sin, cos, tan, arcsin, arccos, arctan
■
Racine de valeurs (
√
a) et sommes de carrés (
√
a
2
+ b
2
)
■
Elévation de valeurs au carré (SQ)
■
Elévation de valeurs à une puissance (^)
■
Constante PI (3,14)
■
Fonctions logarithmiques
■
Fonction exponentielle
■
Inverser logiquement (NEG)
■
Former un nombre entier (INT)
■
Calculer la valeur absolue (ABS)
■
Suppression d'espaces avant la virgule (FRAC)
■
Comparaisons supérieur à, inférieur à, égal à
