![background image](/files/816114/content/doc378.png)
TNC 410, TNC 426, TNC 430 HEIDENHAIN
363
Lettre d'adresse
Fonction
I
Coordonnéé X du centre de cercle/pôle
J
Coordonnée Y du centre de cercle/pôle
K
Coordonnée Z du centre de cercle/pôle
L
Affectation d'un numéro de label avec G98
L
Saut à un numéro de label donné
L
Longueur d'outil avec G99
LA
Nombre de séquences pour pré-calcul avec M120
M
Fonctions auxiliaires
N
Numéro de séquence
P
Paramètres de cycle dans les cycles d'usinage
P
Paramètres dans les définitions de paramètres
Q
Paramètres de programme/paramètres de cycles Q
R
Rayon polaire
R
Rayon de cercle avec G02/G03/G05
R
Rayon d'arrondi avec G25/G26/G27
R
Section de chanfrein avec G24
R
Rayon d'outil avec G99
S
Vitesse de rotation broche
S
Orientation broche avec G36
T
Définition d'outil avec G99
T
Appel d'outil
U
Déplacement linéaire parallèle à l'axe X
V
Déplacement linéaire parallèle à l'axe Y
W
Déplacement linéaire parallèle à l'axe Z
X
Axe X
Y
Axe Y
Z
Axe Z
*
Fin de séquence
Définition paramètre
Fonction
Voir page
D00
Affectation
254
D01
Addition
254
D02
Soustraction
254
D03
Multiplication
254
D04
Division
254
D05
Racine carrée
254
D06
Sinus
256
D07
Cosinus
256
D08
Racine d'une somme de carrés (c =
√
a
2
+ b
2
)
256
D09
Si égal, alors saut
257
D10
Si différent, alors saut
257
D11
Si plus grand, alors saut
257
D12
Si plus petit, alors saut
257
D13
Angle (Angle de c
.
sin
α
et c
.
cos
α
)
256
D14
Numéro d'erreur
259
D15
259
D19
Affectation marqueur automate
259
14.5 Let
tr
es d'adr
esses (DIN/ISO)
Rkap14.pm6
28.06.2006, 14:54
363
