1 p a ramètr es utilisat eur génér aux – HEIDENHAIN TNC 426B (280 472) ISO programming Manuel d'utilisation
Page 360
![background image](/files/816114/content/doc360.png)
TNC 410, TNC 426, TNC 430 HEIDENHAIN
345
Configurer le tableau d‘outils (ne pas exécuter: 0); numéro de colonne dans le tableau d‘outils pour
PM7267.0
Numéro de l‘outil – T: 0 à 5
PM7267.1
Outil spécial – ST: 0 à 5
PM7267.2
Emplacement fixe – F: 0 à 5
PM7267.3
Emplacement bloqué – L: 0 à 5
PM7267.4
Etat de l‘automate – PLC: 0 à 5
Mode de fonctionnement Manuel: Affichage de l'avance
PM7270
N'afficher l'avance F que si une touche de sens d'axe est actionnée: +0
Afficher l'avance F même si aucune touche de sens d'axe n'est
actionnée (avance définie avec la softkey F ou avance de l'axe le plus
„lent“): +1
Vitesse de rotation broche S et fonction auxiliaire M
continuent à être activés après STOP +0
Vitesse de rotation broche S et fonction auxiliaire M
ne sont plus actifs après STOP: +2
Définir le caractère décimal
PM7280
Virgule comme caractère décimal: 0
Point comme caractère décimal: 1
Affichage de positions dans l‘axe d‘outil
PM7285
L‘affichage se réfère au point de référence de l‘outil dans l'axe d'outil: 0
L‘affichage dans l‘axe d‘outil se réfère à la
surface frontale de l‘outil: 1
Résolution d‘affichage pour l‘axe X
PM7290.0
0,1 mm: 0
0,05 mm: 1
0,001 mm: 4
0,01 mm: 2
0,0005 mm: 5 (sauf TNC 410)
0,005 mm: 3
0,0001 mm: 6 (sauf TNC 410)
Résolution d‘affichage pour l‘axe Y
PM7290.1
Valeurs d'introduction: cf. PM7290.0
Résolution d‘affichage pour l‘axe Z
PM7290.2
Valeurs d'introduction: cf. PM7290.0
Résolution d‘affichage pour le 4ème axe
PM7290.3
Valeurs d'introduction: cf. PM7290.0
14.1 P
a
ramètr
es utilisat
eur génér
aux
Rkap14.pm6
28.06.2006, 14:54
345
