8 intr oduir e dir ect ement une f o rmule – HEIDENHAIN TNC 426B (280 472) ISO programming Manuel d'utilisation
Page 279
![background image](/files/816114/content/doc279.png)
10 Programmation: Paramètres Q
264
Fonction de liaison
Softkey
Arc-sinus
Fonction inverse du sinus; définir l'angle issu du
rapport de la perpendiculaire opposée à l'hypothénuse
Ex. Q10 = ASIN 0,75
Arc-cosinus
Fonction inverse du cosinus; définir l'angle issu du
rapport du côté adjacent à l'hypothénuse
Ex. Q11 = ACOS Q40
Arc-tangente
Fonction inverse de la tangente; définir l'angle issu du
rapport entre perpendiculaire et coté adjacent
Ex. Q12 = ATAN Q50
Elever des valeurs à une puissance
Ex. Q15 = 3^3
Constante Pl (3,14159)
Ex. Q15 = PI
Calcul du logarithme naturel (LN) d‘un nombre
nombre de base 2,7183
Ex. Q15 = LN Q11
Calcul logarithme d‘un nombre, nombre de base 10
Ex. Q33 = LOG Q22
Fonction exponentielle, 2,7183 puissance n
Ex. Q1 = EXP Q12
Inversion logique (multiplication par -1)
Ex. Q2 = NEG Q1
Suppression d‘emplacements après la virgule
Calculer un nombre entier
Ex. Q3 = INT Q42
Calcul de la valeur absolue
Ex. Q4 = ABS Q22
Suppression d‘emplacements avant la virgule
Fractionnement
Ex. Q5 = FRAC Q23
Fonction de liaison
Softkey
Vérifier le signe d'un nombre
(sauf TNC 426, TNC 430)
Ex. Q12 = SGN Q50
Si valeur renvoi Q12 = 1: Q50 >= 0
Si valeur renvoi Q12 = 0: Q50 < 0
Règles régissant les calculs
Les formules suivantes régissent la programmation
de formules arithmétiques:
n
Multiplication et division avec addition et
soustraction
N120 Q1 = 5 * 3 + 2 * 10 = 35 *
1ère étape 5 * 3 = 15
2ème étape 2 * 10 = 20
3ème étape 15 + 20 = 35
N130 Q2 = SQ 10 3^3 = 73 *
1ère étape 10 puissance 2 = 100
2ème étape 3 puissance 3 = 27
3ème étape 100 – 27 = 73
n
Règle de distributivité
pour calculs entre parenthèses
a * (b + c) = a * b + a * c
