Sommair e – HEIDENHAIN TNC 426B (280 472) ISO programming Manuel d'utilisation
Page 10
Sommair
e
Sommaire
VI
7 PROGRAMMATION: FONCTIONS AUXILIAIRES ..... 119
7.1
Introduire les fonctions auxiliaires M ..... 120
7.2
Fonctions auxiliaires pour contrôler déroulement du programme, broche et arrosage ..... 121
7.3
Fonctions auxiliaires pour les indications de coordonnées ..... 121
7.4
Fonctions auxiliaires pour le comportement de contournage ..... 124
Arrondi d‘angle: M90 ..... 124
Insérer des transitions de contour entre n'importe quels éléments du contour:
M112 (sauf TNC 426, TNC 430) ..... 125
Filtrage de contours (sauf TNC 426, TNC 430) ..... 127
Usinage de petits éléments de contour: M97 ..... 129
Usinage complet d‘angles de contour ouverts: M98 ..... 130
Facteur d‘avance pour plongées: M103 ..... 131
Vitesse d‘avance aux arcs de cercle: M109/M110/M111 ..... 132
Pré-calcul d'un contour avec correction de rayon (LOOK AHEAD): M120 ..... 132
Autoriser le positionnement avec la manivelle en cours d'exécution du programme:
M118 (sauf TNC 410) ..... 133
7.5
Fonctions auxiliaires pour les axes rotatifs ..... 134
Avance en mm/min. sur les axes rotatifs A, B, C: M116 (sauf TNC 410) ..... 134
Déplacement des axes rotatifs avec optimisation de la course: M126 ..... 134
Réduire l‘affichage d‘un axe rotatif à une valeur inférieure à 360°: M94 ..... 135
Correction automatique de la géométrie de la machine lors de l‘usinage avec axes inclinés:
M114 (sauf TNC 410) ..... 136
Conserver la position de la pointe de l'outil lors du positionnement des axes inclinés (TCPM*):
M128 ..... 137
Arrêt précis aux angles avec transitions de contour non tangentielles: M134 ..... 139
7.6
Fonctions auxiliaires pour machines à découpe laser (sauf TNC 410) ..... 140
Cinhalt.pm6
28.06.2006, 14:54
