HEIDENHAIN iTNC 530 (340 49x-01) ISO programming Manuel d'utilisation
Page 71
![background image](/files/816233/content/doc071.png)
iTNC 530 HEIDENHAIN
71
2.5 Inclinaison du plan d'usinag
e (option logiciel
1)
Machine équipée de tête pivotante
Vous devez amener l'outil à la position d'usinage souhaitée par un
positionnement correspondant de la tête pivotante, par exemple
avec une séquence G0
La position de l'axe d'outil incliné (transformé) change en fonction
du système de coordonnées machine. Faites pivoter la tête
pivotante de votre machine – et par conséquent, l'outil – par
exemple de +90° sur l'axe B. Il y a en même temps rotation du
système de coordonnées. En mode Manuel, si vous appuyez sur
la touche de sens d'axe Z+, l'outil se déplace dans le sens X+ du
système de coordonnées machine.
Pour le calcul du système de coordonnées transformé, la TNC
prend en compte les décalages mécaniques de la tête pivotante
(parties „translationnelles“) ainsi que les décalages provoqués par
l'inclinaison de l'outil (correction de longueur d'outil 3D).
Axes inclinés: Franchissement des points de
référence
Les axes étant inclinés, franchissez les points de référence à l'aide des
touches de sens externes. La TNC interpole alors les axes concernés.
Veillez à ce que la fonction „Inclinaison du plan d'usinage“ soit active
en mode Manuel et que l'angle effectif de l'axe rotatif ait été inscrit
dans le champ de menu.
