FILETAGE EXTERNE SUR TENONS (cycle G267)
1
La TNC positionne l'outil dans l'axe de broche en avance rapide, à
la distance d'approche introduite, au-dessus de la surface de la
pièce
Plongée à la profondeur pour chanfrein
2
La TNC aborde le point initial de la plongée pour chanfrein en
partant du centre du tenon sur l'axe principal du plan d'usinage. La
position du point initial résulte du rayon du filet, du rayon d'outil et
du pas de vis
3
Suivant l'avance de pré-positionnement, l'outil se déplace à la
profondeur pour chanfrein
4
Partant du centre, la TNC positionne l'outil sans correction de
rayon en suivant un demi-cercle; il parcourt la distance entre l'axe
du trou et le chanfrein (décalage jusqu'au chanfrein) et exécute un
déplacement circulaire suivant l'avance de plongée
5
Ensuite, la TNC déplace à nouveau l'outil sur un demi-cercle
jusqu'au point initial
Fraisage de filet
6
La TNC positionne l'outil au point initial s'il n'y a pas eu auparavant
de plongée pour chanfrein. Point initial du filetage = point initial de
la plongée pour chanfrein
7
Avec l'avance de pré-positionnement programmée, l'outil se
déplace sur le plan initial qui résulte du signe du pas de vis, du
mode de fraisage ainsi que du nombre de filets par pas
8
Puis, l'outil se déplace tangentiellement vers le diamètre nominal
du filet en suivant une trajectoire hélicoïdale
9
En fonction du paramètre Nombre de filets par pas, l'outil fraise le
filet en exécutant un déplacement hélicoïdal, plusieurs
déplacements hélicoïdaux décalés ou un déplacement hélicoïdal
continu
10 Puis l’outil quitte le contour par tangentement pour retourner au
point initial dans le plan d’usinage
