Eléments du contour
Droite
Chanfrein
Trajectoire circulaire
Centre de cercle
Rayon du cercle
Trajectoire circulaire avec raccordement tangentiel
Arrondi d'angle
Approche et sortie du contour
sur une droite: tangentielle ou perpendiculaire
sur un cercle
Programmation flexible de
contours FK
Programmation flexible de contours FK en dialogue conversationnel Texte clair
HEIDENHAIN avec aide graphique pour pièces dont la cotation n'est pas conforme à
la programmation des CN
Sauts dans le programme
Sous-programmes
Répétitions de parties de programme
Programme quelconque pris comme sous-programme
Cycles d'usinage
Cycles de perçage pour perçage, perçage profond, alésage à l'alésoir, à l'outil, contre
perçage, taraudage avec ou sans mandrin de compensation
Cycles de fraisage de filets internes et externes
Ebauche et finition de poche rectangulaire et circulaire
Cycles d'usinage ligne à ligne de surfaces planes ou gauchies
Cycles de fraisage de rainures droites ou circulaires
Motifs de points sur un cercle ou sur des lignes
Contour de poche – y compris parallèle au contour
Tracé de contour
En outre, des cycles constructeurs – spécialement développés par le constructeur de
la machine – peuvent être intégrés
Conversion de coordonnées
Décalage du point zéro, rotation, image miroir
Facteur échelle (spécifique de l'axe)
Inclinaison du plan d'usinage (option de logiciel 1)
Paramètres Q
Programmation à l'aide de
variables
Fonctions arithmétiques =, +, –, *, /, sin
α , cos α
Opérations relationnelles (=,
=/, <, >)
Calcul entre parenthèses
tan
α , arc sinus, arc cosinus, arc tangente, a
n
, e
n
, ln, log, valeur absolue d'un nombre,
constante
π , inversion logique, suppression d'emplacements avant ou après la virgule
Fonctions de calcul d'un cercle
Aides à la programmation
Calculatrice
Fonction d'aide proche du contexte lors des messages d'erreur
Aide graphique lors de la programmation des cycles
Séquences de commentaires dans le programme CN
Teach In
Les positions effectives sont prises en compte directement dans le programme CN
Fonctions utilisateur
a
2
b
2
+
a
