8 Programmation: Cycles
8.2 T
a
bleaux de points
8.2 Tableaux de points
Utilisation
Si vous désirez exécuter successivement un ou plusieurs cycles sur
un motif irrégulier de points, vous créez dans ce cas des tableaux de
points.
Si vous utilisez des cycles de perçage, les coordonnées du plan
d'usinage dans le tableau de points correspondent aux coordonnées
des centres des trous. Si vous utilisez des cycles de fraisage, les
coordonnées du plan d'usinage dans le tableau de points correspondent
aux coordonnées du point initial du cycle concerné (ex. coordonnées
du centre d'une poche circulaire). Les coordonnées dans l'axe de
broche correspondent à la coordonnée de la surface de la pièce.
Introduire un tableau de points
Sélectionner le mode Mémorisation/édition de programme:
Appeler le gestionnaire de fichiers: Appuyer sur la
touche PGM MGT.
Introduire le nom et le type de fichier du tableau de
points, valider avec la touche ENT
Sélectionner l'unité de mesure: Appuyer sur MM ou
INCH. La TNC commute vers la fenêtre du
programme et représente un fichier de points vide
Avec la softkey INSERER LIGNE, insérer une nouvelle
ligne et introduire les coordonnées du lieu d'usinage
désiré
Répéter la procédure jusqu'à ce que toutes les coordonnées désirées
soient introduites
NOM DE FICHIER?
Avec les softkeys X OUT/ON, Y OUT/ON, Z OUT/ON
(seconde barre de softkeys), vous définissez les
coordonnées que vous désirez introduire dans le tableau
de points.
NOUV.PNT
