iTNC 530 HEIDENHAIN
447
1
0
.7 F
o
nctions spéciales
Code d'erreur
Texte
1042
Sens du déplacement non défini
1043
Aucun tableau points zéro actif
1044
Erreur position.: Centre 1er axe
1045
Erreur position.: Centre 2ème axe
1046
Diamètre du trou trop petit
1047
Diamètre du trou trop grand
1048
Diamètre du tenon trop petit
1049
Diamètre du tenon trop grand
1050
Poche trop petite: Refaire axe 1
1051
Poche trop petite: Refaire axe 2
1052
Poche trop grande: Rejet axe 1
1053
Poche trop grande: Rejet axe 2
1054
Tenon trop petit: Rejet axe 1
1055
Tenon trop petit: Rejet axe 2
1056
Tenon trop grand: Refaire axe 1
1057
Tenon trop grand: Refaire axe 2
1058
TCHPROBE 425: Longueur dépasse max.
1059
TCHPROBE 425: Longueur inf. min.
1060
TCHPROBE 426: Longueur dépasse max.
1061
TCHPROBE 426: Longueur inf. min.
1062
TCHPROBE 430: Diam. trop grand
1063
TCHPROBE 430: Diam. trop petit
1064
Pas d'axe de mesure défini
1065
Tolérance rupture outil dépassée
1066
Introduire Q247 différent de 0
1067
Introduire Q247 supérieur à 5
1068
Tableau points zéro?
1069
Introduire sens Q351 différent de 0
1070
Diminuer profondeur filetage
1071
Exécuter l'étalonnage
1072
Tolérance dépassée
1073
Amorce de séquence active
1074
ORIENTATION non autorisée
1075
3DROT non autorisée
1076
Activer 3DROT
1077
Introduire profondeur négative
1078
Q303 non défini dans cycle de mesure!
1079
Axe d'outil non autorisé
1080
Valeurs calculées incorrectes
1081
Points de mesure contradictoires
1082
Hauteur de sécurité incorrecte
1083
Mode de plongée contradictoire
1084
Cycle d'usinage non autorisé
1085
Ligne protégée à l'écriture
1086
Aucun angle de pointe défini
