456
10 Programmation: Paramètres Q
1
0
.9 P
a
ra
mètr
es Q réservés
Résultats des mesures réalisées avec les cycles
de palpage
(se reporter également au Manuel d'utilisation Cycles palpeurs)
Valeurs effectives mesurées
Val. paramètre
Angle d'une droite
Q150
Centre axe principal
Q151
Centre axe auxiliaire
Q152
Diamètre
Q153
Longueur poche
Q154
Largeur poche
Q155
Longueur de l'axe sélectionné dans le cycle
Q156
Position de l'axe moyen
Q157
Angle de l'axe A
Q158
Angle de l'axe B
Q159
Coordonnée de l'axe sélectionné dans le
cycle
Q160
Ecart calculé
Val. paramètre
Centre axe principal
Q161
Centre axe auxiliaire
Q162
Diamètre
Q163
Longueur poche
Q164
Largeur poche
Q165
Longueur mesurée
Q166
Position de l'axe moyen
Q167
