5 let tr es d'adr e sses din/iso – HEIDENHAIN iTNC 530 (340 49x-01) ISO programming Manuel d'utilisation
Page 550
![background image](/files/816233/content/doc550.png)
550
13 Tableaux et sommaires
13.5 Let
tr
es d'adr
e
sses DIN/ISO
Cycles d'usinage de
contours complexes
37
120
121
122
123
124
125
127
128
Définition du contour de poche
Données du contour
Pré-perçage (avec G37) SLII
Evidement (avec G37) SLII
Finition en profondeur (avec G37) SLII
Finition latérale (avec G37) SLII
Tracé de contour (avec G37)
Corps d'un cylindre (avec G37)
Corps d'un cylindre, rainurage (avec G37)
Page 340
Page 347
Page 348
Page 349
Page 350
Page 351
Page 352
Page 354
Page 356
Cycles d'usinage ligne à
ligne
60
230
231
232
Exécution de données 3D
Usinage ligne à ligne de surfaces planes
Usinage ligne à ligne de surfaces gauchies
Surfaçage
Page 380
Page 381
Page 383
Page 383
Cycles de conversion de
coordonnées
28
53
54
72
73
80
Image miroir
Décalage du point zéro dans un tableau de points zéro
Décalage du point zéro dans le programme
Facteur échelle
Rotation du système de coordonnées
Plan d'usinage
Page 400
Page 395
Page 394
Page 403
Page 402
Page 404
Cycles spéciaux
04
36
39
62
Temporisation
Orientation broche
Cycle appel de programme, appel du cycle avec G79
Tolérance pour fraisage rapide des contours
Page 411
Page 413
Page 412
Page 414
Cycles d'enregistrement
du déport d'une pièce
400
401
402
403
404
405
Rotation de base à partir de deux points
Rotation de base à partir de deux trous
Rotation de base à partir de deux tenons
Compenser le déport avec l'axe rotatif
Régler directement la rotation de base
Compenser le déport avec l'axe C
cf. Manuel
d'utilisatio
n Cycles
palpeurs
Cycles pour initialiser
automatiquement un
point de référence
410
411
412
413
414
415
416
417
418
419
Point de référence au centre d'une poche rectangulaire
Point de référence au centre d'un tenon rectangulaire
Point de réf. au centre d'une poche/d'un tenon circulaire
Point de référence au centre d'un tenon circulaire
Point de référence intérieur angle
Point de référence extérieur angle
Point de référence au centre d'un cercle de trous
Point de référence dans l'axe du palpeur
Point de référence à l'intersection des lignes joignant deux
fois deux trous
Point de référence sur axe donné
cf. Manuel
d'utilisatio
n Cycles
palpeurs
Groupe
G
Fonction
non modal
pas à pas
Remarque
