8 Programmation: Cycles
8.1 T
ra
v
ailler a
v
e
c les c
y
cles
Groupe de cycles
Softkey
Cycles de fraisage de poches, tenons, rainures
Cycles d'usinage de motifs de points réguliers, ex.
cercle de trous ou surface de trous
Cycles d’usinage ligne à ligne de surfaces planes ou
gauchies
Cycles spéciaux: temporisation, appel de programme,
orientation broche, tolérance
Si vous utilisez des affectations indirectes de paramètres
pour des cycles d'usinage dont le numéro est supérieur à
200 (par ex.D00 Q210 = Q1), une modification du paramètre
affecté (par ex Q1) n'est pas active après la définition du
cycle. Dans ce cas, définissez directement le paramètre
de cycle (par ex. D00 Q210 = 5).
Pour pouvoir exécuter également les cycles d'usinage
G83 à G86, G74 à G78 et G56 à G59 sur les anciennes
commandes de contournage TNC, vous devez
programmer en plus le signe négatif pour la distance
d'approche et pour la profondeur de passe.
