iTNC 530 HEIDENHAIN
341
8.6 Cy
cles SL
Caractéristiques des cycles d'usinage
Avant chaque cycle, la TNC positionne l’outil automatiquement à la
distance d'approche
A chaque niveau de profondeur, le fraisage est réalisé sans
relèvement de l’outil; les îlots sont contournés latéralement
Le rayon des „angles internes“ est programmable – l'outil ne se
bloque pas, permettant ainsi d'éviter les traces de dégagement de
l'outil (ceci est valable pour la trajectoire externe lors de l'évidement
et de la finition latérale)
Lors de la finition latérale, la TNC aborde le contour en suivant une
trajectoire circulaire tangentielle
Lors de la finition en profondeur, la TNC déplace également l'outil en
suivant une trajectoire circulaire tangentielle à la pièce (par ex.: Axe
de broche Z: Trajectoire circulaire dans le plan Z/X)
La TNC usine le contour en continu, en avalant ou en opposition
Introduisez les cotes d'usinage telles que la profondeur de fraisage,
les surépaisseurs et la distance d'approche sous formes de
DONNEES DU CONTOUR dans le cycle G120.
A l’aide de PM7420, vous définissez l’endroit où la TNC
doit positionner l’outil à la fin des cycles G121 à 124.
