8.5 Cy
cles d'usinag
e de motifs de points
8.5 Cycles d'usinage de motifs de
points
Sommaire
La TNC dispose de 2 cycles destinés à l'usinage direct de motifs de
points:
Vous pouvez combiner les cycles d’usinage suivants avec les cycles
G220 et G221:
Cycle
Softkey
G220 MOTIFS DE POINTS SUR UN CERCLE
G221 MOTIFS DE POINTS EN GRILLE
Si vous devez usiner des motifs de points irréguliers,
utilisez dans ce cas les tableaux de points avec G79 “PAT“
(cf. „Tableaux de points” à la page 242).
Cycle G240
CENTRAGE
Cycle G200
PERCAGE
Cycle G201
ALESAGE A L'ALESOIR
Cycle G202
ALESAGE A L'OUTIL
Cycle G203
PERCAGE UNIVERSEL
Cycle G204
CONTRE PERCAGE
Cycle G205
PERCAGE PROFOND UNIVERSEL
Cycle G206
NOUVEAU TARAUDAGE avec mandrin de
compensation
Cycle G207
NOUVEAU TARAUDAGE RIGIDE sans mandrin de
compensation
Cycle G208
FRAISAGE DE TROUS
Cycle G209
TARAUDAGE BRISE-COPEAUX
Cycle G212
FINITION DE POCHE
Cycle G213
FINITION DE TENON
Cycle G214
FINITION DE POCHE CIRCULAIRE
Cycle G215
FINITION DE TENON CIRCULAIRE
Cycle G251
POCHE RECTANGULAIRE
Cycle G252
POCHE CIRCULAIRE
Cycle G253
RAINURAGE
Cycle G254
RAINURE CIRCULAIRE (ne peut pas être combiné
avec le cycle 220)
Cycle G262
FRAISAGE DE FILETS
Cycle G263
FILETAGE SUR UN TOUR
Cycle G264
FILETAGE AVEC PERCAGE
Cycle G265
FILETAGE HELICOÏDAL AVEC PERCAGE
Cycle G267
FILETAGE EXTERNE SUR TENONS
