Introduction
2.4
Affichage d'état
2
70
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
Affichages d'état supplémentaires
L'affichage d'état supplémentaire donne des informations
détaillées sur l'exécution du programme. Il peut être appelé
dans tous les modes de fonctionnement, excepté en mode
Mémorisation/édition de programme.
Activer l'affichage d'état supplémentaire
Appeler la barre des softkeys de partage d'écran
Sélectionner la représentation de l'écran avec
affichage d'état supplémentaire : La TNC affiche le
formulaire d’état
SOMMAIRE dans la moitié droite
de l'écran
Sélectionner l'affichage d'état supplémentaire
Commuter la barre de softkeys jusqu'à l'apparition
de la softkey INFOS
Sélectionner l’affichage d’état supplémentaire
directement par softkey, p. ex. les positions et
coordonnées ou
sélectionner la vue souhaitée au moyen des
softkeys de commutation
Les affichages d'état disponibles décrits ci-après sont à
sélectionner directement par softkeys ou avec les softkeys de
commutation.
Notez que les informations concernant l'affichage
d'état décrites ci-après ne sont disponibles que si
l'option de logiciel correspondante a été validée sur
votre TNC.
