Autres fonctions
8.8
8
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
265
Nom du groupe, Nr. ID.
Numéro Indice
Signification
Palpeur à commutation TS,
350
50
1
Type de palpeur
2
Ligne dans le tableau des palpeurs
51
-
Longueur active
52
1
Rayon actif de bille
2
Rayon d'arrondi
53
1
Excentrement (axe principal)
2
Excentrement (axe secondaire)
54
-
Angle de l’orientation broche en degrés
(excentrement )
55
1
Avance rapide
2
Avance de mesure
56
1
Course de mesure max.
2
Distance d'approche
57
1
Orientation broche possible : 0=non, 1=oui
2
Angle de l'orientation broche
Palpeur de table TT
70
1
Type de palpeur
2
Ligne dans le tableau des palpeurs
71
1
Centre axe principal (système REF)
2
Centre axe secondaire (système REF)
3
Centre axe d'outil (système REF)
72
-
Rayon plateau
75
1
Avance rapide
2
Avance de mesure avec broche immobile
3
Avance de mesure avec broche en rotation
76
1
Course de mesure max.
2
Distance d'approche pour mesure de
longueur
3
Distance d'approche pour mesure de rayon
77
-
Vitesse de rotation broche
78
-
Sens du palpage
