La fonction PLANE : Inclinaison du plan d'usinage
(option de logiciel 1)
11.2
11
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
351
11.2
La fonction PLANE : Inclinaison du
plan d'usinage (option de logiciel 1)
Introduction
Les fonctions d'inclinaison du plan d'usinage doivent
être validées par le constructeur de votre machine!
La fonction
PLANE ne peut être entièrement efficace
que sur des machines qui possèdent au moins
deux axes rotatifs (table et/ou tête). Exception Vous
pouvez également utiliser la fonction
PLANE AXIAL
si un seul axe rotatif est présent ou actif sur votre
machine.
Avec la fonction
PLANE (de l'anglais plane = plan), vous disposez
d'une fonction performante permettant de définir de diverses
manières des plans d'usinage inclinés.
Toutes les fonctions
PLANE disponibles dans la TNC décrivent
le plan d'usinage souhaité indépendamment des axes rotatifs
réellement présents sur votre machine. Vous disposez des
possibilités suivantes :
Fonction
Paramètres nécessaires
Softkey
Page
SPATIAL
Trois angles dans
l'espace
SPA, SPB, SPC
PROJETÉ
Deux angles de
projection
PROPR et
PROMIN ainsi qu'un
angle de rotation
ROT
EULER
Trois angles eulériens
Précession (
EULPR),
Nutation (
EULNU) et
Rotation (
EULROT),
VECTEUR
Vecteur normal pour
définition du plan et
vecteur de base pour
définition du sens de
l'axe X incliné
