![background image](/files/815992/content/doc262.png)
Programmation : paramètres Q
8.8
Autres fonctions
8
262
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
Nom du groupe, Nr. ID.
Numéro Indice
Signification
Valeurs programmées
directement après TOOL
CALL, 60
1
-
Numéro d'outil T
2
-
Axe d'outil actif
0 = X 6 = U
1 = Y 7 = V
2 = Z 8 = W
3
-
Vitesse de broche S
4
-
Surépaisseur longueur d'outil DL
5
-
Surépaisseur rayon d'outil DR
6
-
TOOL CALL automatique
0 = oui, 1 = non
7
-
Surépaisseur rayon d'outil DR2
8
-
Indice d'outil
9
-
Avance active
Valeurs programmées
directement après TOOL
DEF, 61
1
-
Numéro d'outil T
2
-
Longueur
3
-
Rayon
4
-
Indice
5
-
Données d'outil programmées dans TOOL
DEF
1 = oui, 0 = non
Correction d'outil active,
200
1
1 = sans
surépaisseur
2 = avec
surépaisseur
3 = avec
surépaisseur et
surépaisseur de
TOOL CALL
Rayon actif
2
1 = sans
surépaisseur
2 = avec
surépaisseur
3 = avec
surépaisseur et
surépaisseur de
TOOL CALL
Longueur active
3
1 = sans
surépaisseur
2 = avec
surépaisseur
3 = avec
surépaisseur et
surépaisseur de
TOOL CALL
Rayon d'arrondi R2
