Programmation : paramètres Q
8.8
Autres fonctions
8
268
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
FN 19: PLC : Transmettre les valeurs au PLC
La fonction
FN 19: PLC permet de transférer au PLC jusqu'à deux
valeurs numériques ou paramètres Q.
Résolutions et unités de mesure : 0,1 µm ou 0,0001°
Exemple : transférer au PLC la valeur numérique 10
(correspondant à 1µm ou 0,001°)
56 FN 19: PLC=+10/+Q3
FN 20: WAIT FOR: Synchroniser CN et PLC
Vous ne devez utiliser cette fonction qu'en accord
avec le constructeur de votre machine!
Avec la fonction
FN 20: WAIT FOR, vous pouvez synchroniser la CN
et le PLC pendant le déroulement du programme. La CN interrompt
l'usinage jusqu'à ce que soit remplie la condition programmée dans
la séquence FN 20: WAIT FOR-. Pour cela, la TNC peut contrôler
les opérandes PLC suivants :
Opérande
PLC
Abréviation
Plage d'adresses
Marqueur
M
0 à 4999
Entrée
I
0 à 31, 128 à 152
64 à 126
(premier PL 401 B)
192 à 254
(deuxième PL 401 B)
Sortie
O
0 à 30
32 à 62
(premier PL 401 B)
64 à 94
(deuxième PL 401 B)
Compteur
C
48 à 79
Timer
T
0 à 95
Octets
B
0 à 4095
Mot
W
0 à 2047
Double mot
D
2048 à 4095
