Programmer la première pièce 1.3 – HEIDENHAIN TNC 320 (34055x-06) Manuel d'utilisation
Page 49
![background image](/files/815992/content/doc049.png)
Programmer la première pièce
1.3
1
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
49
Introduire Dégager l'outil: appuyer sur la touche
d'axe orange Z pour dégager l'outil dans son axe
et introduisez la valeur de la position à atteindre, p.
ex. 250. Valider avec la touche ENT
Correction de rayon : RL/RR/sans correct.?
Valider avec la touche ENT : Ne pas activer la
correction de rayon
Avance F = ? Valider avec la touche ENT :
déplacement en avance rapide (
FMAX)
FONCTION AUXILIAIRE M ? INTRODUIRE M2 pour
la fin du programme, valider avec la touche END :
la TNC mémorise la séquence de déplacement
Informations détaillées sur ce sujet
Exemple complet avec séquences CN
déplacement linéaire et chanfrein en coordonnées
cartésiennes", Page 193
Créer un nouveau programme : voir "Ouvrir et introduire des
programmes", Page 85
Approche/sortie du contour : voir "Aborder et quitter le contour",
Page 176
Programmer des contours :voir "Sommaire des fonctions de
contournage", Page 184
Types d'avance programmables :voir "Mögliche
Vorschubeingaben"
Correction du rayon d'outil :voir "Correction du rayon d'outil",
Page 165
Fonctions auxiliaires M : voir "Fonctions auxiliaires pour le
contrôle d'exécution de programme, la broche et le liquide de
refroidissement ", Page 309
