HEIDENHAIN TNC 320 (34055x-06) Manuel d'utilisation
Page 420
![background image](/files/815992/content/doc420.png)
Mode manuel et réglages
12.8 Initialiser le point d'origine avec le palpeur 3D
12
420
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
Puis, la TNC déplace le palpeur jusqu'au trou suivant et répète la
même procédure de palpage. Pour déterminer le point d'origine,
répétez cette opération jusqu'à ce que tous les trous soient palpés.
Initialiser le point d'origine au point d'intersection de plusieurs
trous :
Prépositionner le palpeur approximativement au
centre du trou
Le trou doit être palpé automatiquement : à définir
par softkey
Palpage : appuyer sur la touche START externe. Le
palpeur palpe automatiquement le cercle
Répéter l'opération pour les éléments suivants
Terminer l'opération de palpage, passer dans
le menu Exploitation : appuyer sur la softkey
EXPLOITER
Point d'origine : dans la fenêtre du menu,
introduire les deux coordonnées du centre du
cercle, valider avec la softkey INITIAL. POINT
D'ORIGINE ou inscrire les valeurs dans un tableau
(voir "Inscrire les valeurs de mesure à partir des
cycles palpeurs dans le tableau de points zéro",
Page 406 ou voir "Inscrire les valeurs de mesure
des cycles palpeurs dans le tableau Preset",
Page 407)
Quitter la fonction de palpage : appuyer sur la
softkey FIN
