Autres fonctions
8.8
8
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
263
Nom du groupe, Nr. ID.
Numéro Indice
Signification
Transformations actives, 210
1
-
Rotation de base en mode Manuel
2
-
Rotation programmée avec cycle 10
3
-
Axe réfléchi actif
0 : image miroir inactive
+1 : axe X réfléchi
+2 : axe Y réfléchi
+4 : axe Z réfléchi
+64 : axe U réfléchi
+128 : axe V réfléchi
+256 : axe W réfléchi
Combinaisons = somme des différents axes
4
1
Facteur échelle actif axe X
4
2
Facteur échelle actif axe Y
4
3
Facteur échelle actif axe Z
4
7
Facteur échelle actif axe U
4
8
Facteur échelle actif axe V
4
9
Facteur échelle actif axe W
5
1
ROT. 3D axe A
5
2
ROT. 3D axe B
5
3
ROT. 3D axe C
6
-
Inclinaison du plan d'usinage active/
inact. (-1/0) dans un mode Exécution de
programme
7
-
Inclinaison du plan d'usinage active/inact.
(-1/0) dans un mode Manuel
Décalage du point zéro actif,
220
2
1
Axe X
2
Axe Y
3
Axe Z
4
Axe A
5
Axe B
6
Axe C
7
Axe U
8
Axe V
9
Axe W
