Programmation : paramètres Q
8.8
Autres fonctions
8
270
TNC 320 | Manuel d'utilisation HEIDENHAIN-Conversationnel | 7/2013
FN 29: PLC: Transmettre les valeurs au PLC
La fonction FN 29: PLC permet de transférer au PLC jusqu'à huit
valeurs numériques ou paramètres Q.
Résolutions et unités de mesure : 0,1 µm ou 0,0001°
Exemple : transférer au PLC la valeur numérique 10
(correspondant à 1µm ou 0,001°)
56 FN 29: PLC=+10/+Q3/+Q8/+7/+1/+Q5/+Q2/+15
FN 37: EXPORT
La fonction FN 37: EXPORT vous permet de créer vos propres
cycles et de les intégrer dans la TNC. Dans les cycles, les
paramètres Q de 0 à 99 ont uniquement un effet local. Cela signifie
que les paramètres Q n’agissent que dans le programme où ils ont
été définis. A l'aide de la fonction FN 37: EXPORT, vous pouvez
exporter les paramètres Q à effet local vers un autre programme
(qui appelle).
La TNC exporte la valeur qui est celle du paramètre
juste au moment de l’instruction EXPORT.
Le paramètre n'est exporté que vers le programme
qui appelle immédiatement.
Exemple : exporter le paramètre local Q25
56 FN37: EXPORT Q25
Exemple : exporter les paramètres locaux Q25 à Q30
56 FN37: EXPORT Q25 - Q30
